Name: TAEHA 3 Inch Pulse Jet Valve TH-5475-M TH-4475-M Submerged Normally Closed Pulse Jet Valves TH-5475-B TH-4475-B MD03-75 MD03-75M
Brand: YW DKE TRADING COMPANY
Availability: InStock

Thuis Producten Pulsjetkleppen

TAEHA 3 Inch Pulse Jet Valve TH-5475-M TH-4475-M Submerged Normally Closed Pulse Jet Valves TH-5475-B TH-4475-B MD03-75 MD03-75M

Productdetails:

Merknaam:	TAEAHA
Certificering:	CE

Betalen & Verzenden Algemene voorwaarden:

Minimum Order Quantity:	1
Prijs:	Onderhandelbaar
Packaging Details:	Carton
Delivery Time:	1-7Work Days After Payment
Payment Terms:	T/T,Western Union,Paypal
Supply Ability:	5000 Pieces/1Month

Contact

Gedetailleerde productomschrijving

Diaphragm Material:

NBR

Model:

TH-5475-M

Brand:

TAEHA

Fitted Pulse Valve Port:

Markeren:

3 inch submerged pulse jet valve

normally closed pulse jet valve

TAEHA pulse jet valve with warranty

Product Description:

The TH-5475-M is a high-performance submerged pulse valve engineered by TAEHA. With an aluminum die-cast body and NBR oil-resistant diaphragm, it integrates directly with air tanks for stable high-flow purging. All valves are certified by TAEHA lab (Cv flow test), ensuring long-term reliability in standard industrial environments.

Applications:

General Dust Control: Cement grinding stations, grain processing.

Oily Environments: Machine shop oil mist collection, carbon black filtration (NBR oil resistance).

Compact Systems: Woodworking central dust collectors (40% space-saving).

Diaphragm Model No	Pulse Valve Port Size	Pulse Valve Model No
MD01-20 MD02-20	3/4''	TH-5820-B TH-4820-B TH-5825-B TH-5820-C TH-4820-C
MD01-25 MD02-25	1''	TH-4825-B TH-5825-C TH-4825-C TH-5840-F TH-4840-F
MD01-25M	1''	TH-5825-M
MD01-30 MD02-30 MD03-30	1-1/4''	TH-5830-B TH-5430-B TH-4830-B TH-4430-B
MD03-30M	1-1/4''	TH-5430-M TH-4430-M
MD01-40 MD02-40 MD03-40	1 1/2''	TH-5840-B TH-5440-B TH-4840-B TH-4440-B TH-5840-C TH-5440-C TH-4840-C TH-4440-C TH-5850-F TH-5450-F TH-4850-F TH-4450-F
MD03-40M	1-1/2''	TH-5440-M TH-4440-M
MD03-50	2''	TH-5450-B TH-4450-B
MD03-50M	2''	TH-5450-M TH-4450-M
MD03-60 MD04-60	2-1/2''	TH-5460-B TH-4460-B TH-5460-S TH-4460-S
MD03-75	3''	TH-5475-B TH-4475-B
MD03-75M	3''	TH-5475-M TH-4475-M
MD03-90M	3-1/2''	TH-5490-M TH-4490-M
MD03-00M	4''	TH-5400-M TH-4400-M

TAEHA 3 Inch Pulse Jet Valve TH-5475-M TH-4475-M Submerged Normally Closed Pulse Jet Valves TH-5475-B TH-4475-B MD03-75 MD03-75M 0

TAEHA 3 Inch Pulse Jet Valve TH-5475-M TH-4475-M Submerged Normally Closed Pulse Jet Valves TH-5475-B TH-4475-B MD03-75 MD03-75M 1

TAEHA 3 Inch Pulse Jet Valve TH-5475-M TH-4475-M Submerged Normally Closed Pulse Jet Valves TH-5475-B TH-4475-B MD03-75 MD03-75M 2

TAEHA 3 Inch Pulse Jet Valve TH-5475-M TH-4475-M Submerged Normally Closed Pulse Jet Valves TH-5475-B TH-4475-B MD03-75 MD03-75M 3

TAEHA 3 Inch Pulse Jet Valve TH-5475-M TH-4475-M Submerged Normally Closed Pulse Jet Valves TH-5475-B TH-4475-B MD03-75 MD03-75M 4
